| 設備類型 | 控制臺 |
|---|---|
| OEM | 可OEM |
| 質保 | 三年（年） |
| 型號 | ARK-3440 |
| 品牌 | 研華 |
高性能Intel ® Core™ i7嵌入式解決方案，支持PCIe擴展槽，雙SATA HDD，適用于圖像處理及視頻監控等應用
主要特征
無風扇Intel ® Core™ i7酷睿超緊湊嵌入式工控機支持高分辨率多媒體寬屏顯示支持2個GbE, eSATA, 6個USB 2.0,音頻和3個COM接口2個內置2.5" SATA硬盤驅動托架支持各種不同的應用擴展接口6個可編程功能鍵易于集成，易于維修，寬幅輸入電壓IP40防護等級Specifications
| ARK-3440F-U4A1E | |
Processor System | CPU | Intel® Core i7 SV up to 2.53 GHz / Intel® Core i5 SV 2.4GHz |
System Chipset | Intel® QM57 chipset | |
BIOS | AMI 64 Mbit, SPI | |
Memory | Technology | DDR3 1066 MHz |
Max. Capacity | 4 GB | |
Socket | 2 x 204-pin SODIMM | |
Graphics | Chipset | Integrated graphics built in Intel® QM57 |
Interface | CRT Interface (Optional by cable) / DVI Interface, compliant with DVI 1.0 / HDMI 1.3 / 24-bit LVDS interface(Optional) | |
Ethernet | LAN1 | 10/100/1000 Mbps Ethernet controller, support Wake On LAN |
LAN2 | 10/100/1000 Mbps Ethernet controller, support Wake On LAN | |
Audio | Amplifier | Dual output 2.2 W amplifier |
Interface | Spkr-out, Mic-in, Line-in | |
I/O Interface | Serial Interface | 2 x RS232, 1 x RS232/422/485 (w/ auto flow control) |
USB Interface | 6 x USB ports, Compliant with USB 2.0 | |
Parallel Port | Supports D-sub 25-pin connector | |
Digital I/O | Support 16-bit digital IO (optional) | |
Other | Thermal Alarm | Yellow LED lighting |
Watchdog Timer | 255 levels timer interval, setup by software | |
Function Key | 6 programmable functional keys (for ARK-3440A available only) | |
Expansion | ISA/PCI/PCIe Slot | 1 Slot PCI and 1 Slot PCIe x1 (default) / 2 Slots PCIe x1 (optional); 2 Slots PCI(optional) ; 1 Slot PCI and 1 Slot PCIe x4 |
Mini PCI/Mini PCIe | 2 x Mini PCIe | |
Storage | HDD | Supports drive bay space for 2 x SATA 2.5" HDD |
SSD | Supports CompactFlash socket for type I/II CompactFlash disk | |
Software Support | Microsoft Windows | Win 7, XP Professional, XP Embedded |
Linux | Fedora 9 | |
Power Requirement | Power Type | AT/ATX |
Power Input Votage | 9 VDC ~ 34 VDC | |
Minimum Power Input | DC 9-34V @ 6.0-1.5A | |
Power Adapter | AC to DC, DC19V/7.89A, 150W (Optional) | |
Power Consumption | Typical | 38 W (with is Intel @ Core i7-610E at 2.53 GHz and w/o expansion) |
Max. | 47.94 W (with is Intel @ Core i7-610E at 2.53 GHz and w/o expansion) | |
Mechanical | Construction | Aluminum housing |
Mounting | Desk/wall-mounting | |
| 220 mmx 102.5 mm x 200 mm (8.66" x 4.04" x 7.87") | |
Weight | 4 kg(8.8 lb) | |
Environment | Operating Temperature | With extend temperature peripherals CompactFlash disk: 0 ~ 50° C / with extend temperature peripherals 2.5-inch hard disk 0° to 45°C, with air flow |
Storage Temperature | - 40 ~ 85° C (-40 ~185° F) | |
Relative Humidity | 95% @ 40° C (non-condensing) | |
Vibration Loading During Operation | With CompactFlash disk: 5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 Oct./min, 1 hr/axis. / With 2.5-inch hard disk: 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 Oct./min, 1 hr/axis. | |
Shock During Operation | With CompactFlash disk: 50 G, IEC 60068-2-27, half sine, 11 ms duration / With hard disk: 20 G, IEC 60068-2-27, half sine, 11 ms duration | |
EMC | CE/FCC Class A, CCC, BSMI | |
Safety Certifications | UL, CCC, BSMI | |
